Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter

Yiwu Soonest New Energy Co., Ltd.
Contact Now
    Buy cheap Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter from wholesalers

    Buy cheap Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter from wholesalers
    • Buy cheap Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter from wholesalers
    • Buy cheap Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter from wholesalers
    • Buy cheap Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter from wholesalers
    • Buy cheap Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter from wholesalers
    • Buy cheap Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter from wholesalers
    • Buy cheap Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter from wholesalers

    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter

    Ask Lasest Price
    Brand Name : Growatt
    Model Number : 10kw
    Supply Ability : 1000 Box/Boxes per Week
    Price : $389.60/boxes 1-299 boxes
    • Product Details
    • Company Profile

    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter

    Products Description
    Datasheet
    SPF 3500 ES
    SPF 5000 ES
    Battery Voltage
    48VDC
    Battery Type
    Lithium/Lead-acid
    INVERTER OUTPUT
    Rated Power
    3500VA/3500W
    5000VA/5000W
    Parallel Capabillty
    Yes, 6 units maximum
    AC Voltage Regulation (Battery Mode)
    230VAC±5%@50/60HZ
    Surge Power
    7000VA
    10000VA
    Efficiency(Peck)
    93%
    Waveform
    Pure sine wave
    Transfer Time
    10ms typical,20ms Max
    SOLAR CHARGER
    Maximum PV Array Power
    4500W
    6000W
    MPPT Range@Operating Voltage
    120VDC-430VDC
    Number of Independent MPPT Trackers/Strings Per MPP Tracker
    1/1
    Maximum PV Array Open Circuit Voltage
    450VDC
    Maximum Solar Charge Current
    80A
    100A
    AC CHARGER
    Charge Current
    60A
    80A
    AC Input Voltage
    230VAC
    Selectable Voltage Range
    170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances)
    Frequency Range
    50HZ/60HZ (Auto Sensing)
    PHYSICAL
    Protection Degree
    IP20
    Dimension(W/H/D)
    330/485/135MM
    330/485/135MM
    Net Weight
    11.5kgs
    12kgs
    OPERATING ENVIRONMENT
    Humidity
    5% to 95% Relative Humidity(Non-condensing)
    Altitude
    <2000m
    Operating Temperature
    0°C-55°C
    Storage Temperature
    -15°C-60°C
    Working Modes Applications
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Product Details
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Company Profile
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
    Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter

    1,Q:Why your quotation is higher than other suppliers? A:In domestic market, the high and low inverter brands are mixed together. There are many low-cost inverter is actually some assembled small unlicensed workshops, it crudely, to reduce costs and use of substandard components for assembly, there is a very big security risk! In order to protect the pro personal and property safety, please do not covet low price, be sure to choose a reliable inverter! .............................................................................................................................................................. 2,Q:How many categories does it have according to the output waveform ? A:Type one: Modified Sine Wave inverter, which uses PWM pulse width modulation to generate modified sine wave. Due to the usage of intelligent dedicated circuit and high power field effect tube, it greatly reduces the power loss and increases the soft-start function, effectively ensuring the reliability of the inverter. If the power quality is not highly demanded, it is able to meet the needs of most electrical equipment. But it still exists 20% harmonic distortion problems when running sophisticated equipment, can also cause high-frequency interference to radio communications equipment. This kind of inverter can meet the basic needs of most of our power, high efficiency, small noise, moderate price, and thus become the mainstream products in the market. Type two: Pure Sine Wave inverter, which adopts isolated coupling circuit design, high efficiency, high stability of the output waveform, high-frequency technology, small in size, suitable for all kinds of load, can be connected to any common electrical devices and inductive load devices (such as refrigerators, electric drill, etc.) without any interference (eg: buzz andTV noise). The output of pure sine wave inverter is the same as the grid tie power we daily used, or even better, because it does not exist grid tie electromagnetic pollution. .............................................................................................................................................................. 3,Q:Is the output voltage of our inverter stable ? A:Absolutely. Our inverter is designed with a good regulator circuit. You can even check it when measuring the true value by a multimeter. Actually the output voltage is quite stable. Here we need make a especial explanation : many customers found it is unstable when using conventional multimeter to measure voltage. We can say the operation is incorrect. Ordinary multimeter can only test pure sine waveform and calculate datas. .............................................................................................................................................................. 4,Q:What is a resistive load appliances? A:Generally speaking, appliances like mobile phones, computers, LCD TVs, incandescents, electric fans, video broadcast, small printers, electric mahjong machines, rice cookers etc. All belong to resistive loads. Our modified sine wave inverters can drive them successfully. .............................................................................................................................................................. 5,Q:What is the inductive load appliances? A:It refers to the application of electromagnetic induction’s principle, produced by high-power electrical products, such as motor type, compressors, relays, fluorescent lamps, electric stove, refrigerator, air conditioner, energy saving lamps, pumps, etc. These products’power are far more than the rated power (about 3-7 times) when start. So only pure sine wave inverter is available to them. .............................................................................................................................................................. 6,Q:What should be noticed when installing inverter? A:Put the product in a place where is well ventilate,cool, dry and water-proof. Pls do not stress and do not put foreign objects into the inverter.Rember to turn on the inverter before turn on the appliance.
